Features:
Designed with the Higher Capacity
Precise and Automatic Control of Room Temperature in Two-Pipe Systems by Modulating the Flow of Hot Water or Steam Through High Capacity Heating Unit
Normally Open without Control Mounted
Specifications:
Manufacturer: Honeywell
Manufacturer Part Number: V110F1018
Product Type: Radiator Valve
Body Configuration: Horizontal Angle
Nominal Size: 1"
End Connection: Male Threaded x Female Threaded
Body Material: Nickel Plated Bronze
Seat Material: EPDM
Temperature Rating: 248 Degrees F
Pressure Rating: 150 PSI (Hot Water), 15 PSI (Steam)
Differential Pressure Rating: 17 PSI
Capacity: 193000 BTU/Hour
Dimensions: 5.7" x 4" x 2.85"
Weight: 1.73 lb.
Used For: Valve Seat Disc, Cartridge
